Cerwin Vega XED3002D XED Series 2 Channel Car Amplifier - 120W x 2 @2Ohms, 250W Max Power Class D - Perfect for Car Audio Systems & Bass Boost Upgrades

Product Description

Features:

• Latest High-Efficiency Class D Topology
• Compact Size with Ambient backlit logo
• RCA “Pass Thru” output for easy system expansion
• Fully Variable Crossovers (12dB per octave)
• Handles HI and LO level input to 12V
• 2 Ω Stable Stereo and 4Ω Mono (CH3/4) for 3 Ch mode
• Proprietary Vega Bass Boost EQ Up To 12dB

Specifications:

• Amplifier Power: 250W MAX
• RMS Power(2Ω): 2 x 120W
• RMS Power (4Ω): 2 x 80W
• RMS Bridge (mono 4Ω): 1 x 220W
• Types: Class D
• Power Supply: Full PWM
• Power Supply (Threshold): 10.0DVC – 16.0DVC
• Idle Current: (0.5A)
• Distortion - THD (1KHz@4Ω): <0.1%
• Distortion - S/N Ratio (A weight @ 1W): -85dBA
• Distortion - S/N Ratio (A weight @ FP): -101.1dBA
• Input Sensitivity - Hi/Low Input Level 1.3V ~>20.0V / 250mV – 6.0V
• Input Impedance - Low Input Level 20 KΩ
• Input Impedance - High Input Level 100 KΩ
• Output Impedance 2 Ω
• Damping Factor (50Hz@4Ω) >70
• Bandwidth (-3dB) 10Hz-30KHz
• Crossover (-12 dB/ Oct) Variable High-Pass 35Hz-250Hz
• Crossover (-12 dB/ Oct) Variable Low-Pass 35Hz-250Hz
• Crossover (-12 dB/ Oct) Variable Sub-Sonic N/A
• FUSE Ratings - ATC 20A
• Dimension - Length x Width x Height - Inches(mm): 6.3 x 4.7 x 1.8 (160 x 120 x 46.5)
