Cerwin Vega VCU84 1200W Peak 500W RMS Class D 4 Channel Marine Amplifier - High Power Waterproof Boat Audio System for Marine, Yacht, and Outdoor Adventures

Product Description

Features:

• Class-D Full Range 4-Ohm Stable 4-Channel Amplifier
• RMS Power Rating:
• 4 ohms: 80 watts x 4 chan
• 2 ohms: 150 watts x 4 chan.
• 1 ohm: ------------N/A------------
• Bridged, 4 ohms: 300 watts x 2 chan.
• Total power output: 550 watts
• Compact Universal All-Weather Application
• CEA-2006 Compliant Amplifier
• Pulse Width Modulated MOSFET power supply
• High-Power Digital Class D Advanced Technology IR Chipset
• Wired remote bass level control included
• LED power (green) and protect (red) indicators
• Soft start turn-on
• 2/4 channel operation
• Preamp RCA outputs to daisy chain multiple amps
• 3-way protection circuitry (thermal, overload, and speaker short protection)
• Dual speaker terminals simplify the hookup of multiple speakers
• Heavy duty aluminum alloy heat-sink for extreme heat dissipation
• Input sensitivity: 200mV-10V
• Frequency Response: 10 - 30000 Hz
• Total Harmonic Distortion (THD): 0.5%
• Signal to Noise Ratio: >85 dB
• Channel Separation: >55 dB
• Variable high-pass filter: 40 - 400 Hz, 24 dB/octave
• Variable low-pass filter: 40 - 400 Hz, 24 dB/octave
• Variable Bass Boost: 0 to +12 dB bass boost at 45 Hz
• Fuse Rating: 40 A x 2
